Flatbed equipment transporter with crane
- Maximum Lifting Capacity
- 8 / 9 / 13 / 16 t
- Deck Payload
- 1–40 t
- Engine Options
- Multi-brand engine / chassis options
- Loading Ramps
- Hydraulic / spring-assisted
- Drive Options
- 4×2 / 4×4 / 6×4 / 6×6 / 8×4
- Emission Standard
- Euro 2–6
Reference configuration. Final values are confirmed for the selected chassis, model and destination.
About the flatbed equipment transporter with crane
The KEEYAK Flatbed Equipment Transporter with Crane is a machinery carrier combining a load deck with an integrated loader crane. Its maximum lifting capacities are 8 / 9 / 13 / 16 t, while 1–40 t describes the separate deck-payload range. Maximum lifting capacity applies only under the conditions stated in the selected crane model's load chart. Capacity decreases as working radius and boom extension increase.
It suits equipment rental companies, contractors, utilities, and field service fleets handling mixed machinery and parts. Review equipment mass and dimensions against deck geometry and axle distribution. The loading method must suit the crane radius and site support, with adequate ground clearance. Confirm securement points for the carried equipment. Final chassis matching, axle-load calculation, equipment model, load chart, and destination compliance shall be confirmed in the signed technical specification.
Typical applications
Compact machinery delivery
The crane-equipped flatbed transports compatible compact equipment and can handle separate buckets, tools, or attachments when each lift fits the verified chart.
Equipment attachment exchange
Rental and construction fleets deliver attachments to jobsites, using the onboard crane to place components without relying on customer lifting equipment.
Field repair support
Service teams carry machinery parts and lifting equipment to remote sites, then position compatible components for controlled maintenance or replacement work.
Utility equipment deployment
Utilities transport cabinets, pumps, generators, or specialized tools and unload them near prepared work areas with confirmed lifting and ground conditions.
Before you order
How are lifting capacity and transport payload checked?
Check the proposed lift against the selected crane's load chart at the required radius and extension. Separately check the machinery's mass, dimensions and position on the deck against deck and axle limits. A load that the crane can lift is not automatically a load the completed truck can carry.
