How should buyers check the crane lift and flatbed transport load?

Check deck fit and carrying capacity for the recovered vehicle, then assess the crane independently at the required radius. Crane, subframe and stabilizer mass reduce the remaining truck payload. Confirm both the loading operation and the final carried-load position on the approved layout.

Which local rules affect the Flatbed Wrecker with Crane specification?

Before ordering the Flatbed Wrecker with Crane, the importer should verify destination vehicle registration, equipment inspection, operator qualification, work-zone, and road-use requirements. These rules may affect the required equipment specifications and ratings, stability systems, chassis loading, controls and documentation.

Which Flatbed Wrecker with Crane parts need protection during sea transport?

Stow and secure the deck and crane as separate assemblies, using their documented transport provisions. Restrain any fitted stabilizers, ropes, ramps and attachments. Do not list an underlift unless it is included in this build; confirm the combined stowed dimensions with the carrier.

Which conditions can restrict Flatbed Wrecker with Crane use?

Stop operating the Flatbed Wrecker with Crane if any of these conditions falls outside the approved work plan: ground bearing capacity, working radius, overhead clearance or wind conditions.

How should buyers verify the completed Flatbed Wrecker with Crane?

Inspect the deck, restraints and loading geometry alongside the installed crane’s identity, chart and safety functions. Record the completed axle checks and agreed tests for both systems. A successful crane demonstration does not establish deck capacity, and an empty-deck test does not verify the crane installation.

Flatbed wrecker with crane

Flatbed Length: 4000–7000 mm
Flatbed Load Capacity: 5 t
Winch rating (basis to be confirmed): 4–15 t
Rear tow boom rating (basis to be confirmed): 2.5–15 t
Crane Type: Telescopic / Knuckle
Crane Capacity: Model-specific; confirmed against the installed crane's load chart

Reference configuration. Final values are confirmed for the selected chassis, model and destination.

About the flatbed wrecker with crane

The KEEYAK Flatbed Wrecker with Crane is a recovery carrier combining a tilting transport deck with a vehicle-mounted lifting boom. Its flatbed load capacity is 5 t. Crane lifting capacity is separate from deck capacity and must be confirmed against the installed crane's load chart, working radius, and stabilizer arrangement. Flatbed load capacity, winch line pull, wheel-lift rating, and towing capacity are separate ratings and shall not be used interchangeably.

It suits towing contractors, fleet workshops, equipment dealers, and roadside recovery teams managing damaged vehicles, inaccessible loading positions, or compact machinery. Assess lifted mass at the required crane reach and working radius. Deck capacity must be checked separately against chassis loading. The stabilizing arrangement must suit site conditions, with tie-down points for the carried load. Final chassis matching, axle-load calculation, equipment model, load chart, and destination compliance shall be confirmed in the signed technical specification.

Line drawing of a flatbed recovery truck with a crane behind the cab.

Typical applications

Off-road vehicle retrieval
The crane can assist retrieval toward the deck only where its chart, rigging plan and ground support cover the required load and radius. Deck capacity is checked separately for transport.
Accident vehicle loading
At collision scenes, damaged vehicles with blocked wheels or compromised steering can be lifted or aligned before controlled deck loading and securement.
Compact equipment transport
Workshops and rental fleets use the flat deck for compact equipment, while the lifting boom assists loading only within approved radius and capacity limits.
Restricted-access recovery sites
Where a barrier prevents direct deck access, assess the crane’s complete reach path and load chart. The ability to reach a point does not establish permission to lift from it.

Before you order

Which buyers should consider the flatbed wrecker with crane?

This combination can suit a recovery where a separately assessed crane lift helps place the vehicle or equipment onto a transport deck. Check the lift and road-carried load independently. If direct deck loading is sufficient, compare the payload and complexity of a flatbed without the crane.
